The post will briefly introduce what RF-WM-3220B1 WiFi module is, what features it has and where it is applied in. What is RF-WM-3220B1 WiFi module? RF-WM-3220B1 is a Wi-Fi IoT module built on basis of TI CC320SF IC, which is embedded with a Cortex-M4 MCU. It supports a variety of peripherals i.e. camera interface, I²S, SD/MMC, UART, SPI, I²C, ADC and GPIO. The module supports IEEE 802.11 b/g/n standards, and is able to work at Station, AP and Wi-Fi Direct modes. Antenna wise, it offers 3 options: ceramic antenna, IPEX base and antenna welding. RF-WM-3220B1 supports TCP/IP protocols and relevant applications. It can be widely applied in a big variety of IoT scenarios i.e. home automation, home appliance control, security systems, smart energy, internet gateway, industrial control, smart metering, wireless audio, wireless doorbell and sensor networking nodes etc. The module has two operation modes: AT Command Mode and Data Transparent Transmission Mode. With AT Command Mode, the developer can write a series of AT commands to route the transmission of the data. While in Data Transparent Transmission Mode, the modules automatically transmit the data by broadcasting the UDP packets with designated destinations. The developer or user does not have to instruct how the data transmission is routed in the latter mode. However, to switch between operation modes for the network or change the work mode of a module, the user has to use some simple AT commands to instruct the modules. Applications of RF-WM-3220B1 WiFi module Features of RF-WM-3220B1 WiFi module The module which works at Station mode can exchange data between any devices in the LAN, beside it can through a router to enter the internet, and communicate among remote devices. One module works at AP mode as TCP Server, and the other modules works at Station mode as TCP Client to communicate with it. Pin Assignment Package Size Module Thickness No. Parameter item Parameter details Description 1 Chip CC3220SF TI 2 Size 31*20mm - 3 Weight 5g - 4 Frequency Band 2402 MHz ～ 2480MHz   6 PCB 4-layer Impedance-matching, lead-free 7 Supply Voltage 2.3~3.6V DC The voltage higher than 3.6V is forbidden 8 Operation Range 100m Open area; +17dBm; 9 Max Power Max +17dBm 50mW 10 Power consumption Averge:1.AP Mode:74mA                                    2.STA mode Active:20mA                      3.STA Mode Always                                Connected(Long Sleep                          Intervals:400ms):1.5mA   4.STA Mode Hibernate:35uA 11 Communication interface IO See details in Pin definition 12 Antenna type PCB/IPEX 50Ω characteristic impedance/- 13 Operating temperature -40 ~ +85℃ Industrial-grade 14 Operating hum...

ZigBee 3.0 is the only complete and interoperable Internet of things solution, which enables intelligent products to work together from mesh network layer to general language layer. Why ZigBee 3.0 ZigBee 3.0 gives users and developers more options. The standardization of the whole stack covers chips from multiple chip suppliers, ZigBee Pro network protocol stack, and ZigBee cluster Library in application layer, bringing confidence that products and services can work together. ZigBee 3.0 complete solution includes testing, certification, brand and marketing support, making the development and sales of interoperable products and solutions easier, releasing growth opportunities, and giving unlimited innovation possibilities for home, work and travel. RF-star provides the most advanced ZigBee 3.0 module in the industry. Users can use the ZigBee 3.0 module of RF-star for secondary development or in-depth cooperative development with RF-star. ZigBee 3.0 advantages Interoperability Certification procedures ensure interoperability between devices Multi vendor ecosystem uses the same application layer common language ZigBee 3.0 network can be used for devices using previous application layer standards ZigBee 3.0 equipment can also be added to the network using the previous application layer standards Different industries, same plan Home, architecture, industry, retail, health, etc Developers and users in different fields have the same choice to solve the problem of market fragmentation The same application layer can meet the requirements of the complete deployment scheme Convenient and easy to use All the required files are in one place The same certification mark shall be used on each certified product and package Stable and reliable Proven mesh network, eliminating the impact of single node failure, can be expanded to large-scale network Self healing and scalable, capable of supporting a network of hundreds of devices Global general Use 2.4 GHz frequency band to ensure that the product can be deployed globally free of frequency band license fee Practice verification · 2500 certified products and 300 million deployed products Green environmental protection Specially designed for energy capture devices and ultra-low power consumption devices ZigBee routers all have green power proxy function to provide mesh network support for energy capture devices Future guarantee Developed by more than 400 member companies who have been deeply involved in the Internet of things industry for many years and launched to the market Continuous innovation - in our ecosystem, there are not only industry giants, established enterprises, but also start-ups and new forces Complete test The integrated test and authentication program covers all layers of protocol stack: MAC / PHY, network stack protocol and application layer Examples of ZigBee Application Equipment

The annual CES (Consumer Electronics Show) opened in Las Vegas on January 6, 2016. As a world-renowned science and technology event, the concepts discussed in CES will become a hot topic in the next two to three years. However, in this CES, which seems to have no core theme, there are many things that are observed by interested people: the Internet of things, smart home, virtual reality, etc. More importantly, the combination of Internet of things and cloud computing. "Lazy economy" is being talked about by more and more people, or will become the new economic growth point of smart home in the next few years. An interesting phenomenon is that the concept of the lazy economy is very popular both at home and abroad. Although o2o has been used for many times since the beginning of the year, and now it has been slightly eased, the concept never seems to cool down. As Shahid Ahmed, a senior executive of PWC, said, "in the field of Internet of things, we have reached a turning point: the integration of consumer experience, digital technology and sensor technology." Fortunately, with the continuous development of related technologies, the smart home industry based on the home Internet of things can capture the "lazy economy" as a new growth field - the convenient life at your fingertips, which is the choice of the middle class who cares about saving time and is willing to try. What's more, "lazy people" are not idle, but to further liberate more time and energy to invest in more worthy areas. This coincides with the original intention of smart home interest: to make people's lives truly free and convenient through technology. What the "lazy man" requires is to work out the most reasonable scheme by intelligent calculation according to the actual situation in the simplest operation as possible, and to realize the requirements of accuracy and complexity as efficiently as possible. This requires not only technical support, but also the thinking close to the user's actual experience, otherwise it will become a chicken ribs. In fact, in the smart home industry, sharp manufacturers at home and abroad have caught the pass of this node, and timely launched a variety of products that are convenient for the user's life: sweeper robot, automatic fast food machine, intelligent lighting adjustment, intelligent door lock, etc. In terms of smart door lock, this CES is like the W2 walnut smart lock of CEI, which realizes the remote door opening and closing service of "cloud key", and provides a good experience for "lazy people" to break the space limit. It is worth noting that local excellent original manufacturers also have outstanding performance in the field of smart home, and they have also upgraded and fermented in the domestic market in recent years. There is no doubt that smart home based on "lazy economy" has great development potential. According to the latest report released by research and markets, it is predicted that the global smart home market will grow ...

During January 6 to 9th 2015, the 47th Consumer Electronics Show( CES ) held successfully in Las Vegas with world's attention. In the last 2014, the smart home market have been got more attention from the media,enterprise and public. After a year of rapid development,smart home is one of the main characters in this CES that intelligent solutions and smart products attracted the public's attention. RF-star displayed intelligent lighting solution which enjoyed winning and popular at TI booth in CES. TI LPRF General Manager Oyvind Birkenes, RF-star CEO King Kang and TI LPRF Product Line Manager Jan-BJ rnar Lund RF-star smart lighting solution shows in TI booth in CES In recent years, in addition to the smart lighting solutions, RF-star has developed a series of smart solutions of consumer electronic products with customization, such as smart R/C toy, smart bracelet, ibeacon, anti-lost tracker, bluetooth e-cigarette, bluetooth e-scale, and etc. To prompt customers' commercialization and meet market demands, RF-star would make more efforts in RF applications with advanced technology.

The 19th Guangzhou International Lighting Exhibition is at hand. The exhibition, which is referred to as the “Oscar for Lighting Industry”, is expected to get more than 200000 visitors from 27 countries. 2,588 exhibitors will gather to show the most comprehensive lighting appliances, light sources and accessories, which covers the whole LED industrial chain of products and technologies. The characteristic of the exhibition this year may probably be a little different from the previous. In 2013, the exhibition saw the three trends of the development in the LED lighting industry as below: smart lighting, engineering project and LED technology integration. This year, the exhibition will promote the development of innovations in the above-mentioned hotspots, and strengthen the understanding to the hotspots in the industry. The organizer will also be hold 120 summit forums or communication activities, to discuss the latest lighting technology and new thoughts of design, and to expand cooperation opportunities. As a leading developer of wireless connection solution, RF-star will also attend this exhibition, in the name of Texas Instruments, and display the latest smart light control solutions, important wireless modules and end-use products. As the biggest wireless connection solution design developers of TI in China, RF-star has developed a series of innovative lighting control solutions on the basis of TI chip technology. They are also consistent with the current developing trend and hotspot of the exhibition this year. At present, RF-star has already established firm cooperation with many well-known domestic lighting manufacturers, who will also take part in the exhibition and release their latest and coolest smart lighting products under our co-work. As it is known, LED lighting has a great market demand, as the substitute to traditional incandescent lighting. Meantime there is no doubt that the LED lighting industry has entered in the era of intense competition. However, the Bluetooth Smart lighting solution developed by RF-star will provide more value growths to this industry. It helps LED lighting enterprises to keep up with the quick development of Internet of Things, and to realize the development and promotion of the enterprise. It is just a jump, with limited investment, and you will be in the field of Smart Home. We are glad to invite you to attend the 19th Guangzhou International Lighting Exhibition. And you are welcome to visit Booth E02 in Hall 13.2, where you will see the latest smart lighting development and an opportunity to start our collaboration in depth.

Smart locks and smart sensors have become more and more trendy. Developers can spend a huge amount of time creating and connecting these popular Internet of Things (IoT) products to the cloud via gateways using wireless technologies such as Bluetooth® low energy(LE). Choosing an easy-to-use cloud service that offers powerful functions, steadiness and multiple cloud-security features can also be a challenge, so RF-star and TI worked with Alibaba to provide support for the Ali Cloud Link IoT platform on RF-star Bluetooth low energy CC2640R2F wireless module. RF-star provides a sample application for the CC2640R2F module software development kit (SDK) to support Ali Cloud Link. Through this sample application, you can receive the specific Alibaba profile, which contains a range of security features, over-the-air (OTA) support and good performance for compatibility with iOS and Android platforms. For example, you can use the secure hash algorithm (SHA) 256 security feature and the CC2640R2F wireless module’s true random number generator (TRNG) to generate keys for Advanced Encryption Standard (AES) encryption, which is included in the CC2640R2F device’s hardware encryption engine. This ensures that every communication session gets a different key to improve the security performance for data transmission. With a few simple application programming interfaces (APIs), you can build up a secure Bluetooth low energy product. The Alibaba OTA protocol is fully supported in this sample application. Compatibility with different Android mobile phones has been optimized, especially for China-brand Android phones. Figure 1 shows the architecture of a sample application with theTI CC2640R2F SDK. Figure 1: SDK software architecture for the CC2640R2F wireless module The 2.4GHz  CC2640R2F wireless module supports Bluetooth 4.2 and Bluetooth 5 ultra-low-power applications for IoT applications. The device has extremely low active radio frequency (RF), MCU power and low-power-consumption modes, thus enabling longer battery life. It includes a 32-bit Arm® Cortex®-M3 core as well as many peripheral functions in which there is a unique ultra-low-power sensor controller. The sensor controller is suited for connecting external sensors, and automatically collecting analog and digital data when the rest of the system is in sleep mode. You do not have to worry about issues like protocol interaction and driver development. The CC2640R2F SDK includes: Application code that is 100% portable across the SimpleLink MCU platform from Bluetooth low energy to Sub-1 GHz and more. RFSTAR drivers that provide a standard and unified API interface for all peripheral interfaces of the ti SimpleLink MCU platform, enabling you to write code independent of the targeted device. The integrated TI real-time operating system (TI-RTOS). Other RTOSs like Free RTOS’s adapter interface, which is API-compatible to the Portable Operating System Interface for Unix (POSIX). A hardware encry...
